RF Tunnel Shielded Chamber for Reliable OTA Testing

The RF Tunnel Shielded Chamber from Orbis Systems is a fully shielded, configurable enclosure designed for reliable over-the-air (OTA) testing with repeatable measurements free from external interference.

Built on Orbis’ proven OTA and RF shielding platforms, the tunnel chamber integrates Precision antenna positioning and DUT interfaces, enabling efficient and automated validation of wireless products.

The solution supports both Sub-6 GHz (FR1) and mmWave (FR2) frequency ranges, making it suitable for comprehensive 5G device and base station testing.

Technical Skills

Comprehensive RF shielding: Prevents outside electromagnetic interference from entering the test volume and minimizes internal leakage, ensuring accurate and repeatable OTA measurements.

Integrated positioning and automation: Works with Orbis antenna positioners and DUT controllers (standard REST API support) to automate antenna, beamforming, MIMO, and throughput testing.
Modular form factors: Available as tunnel-style shielded rooms, container-based OTA chambers, or compact shielded boxes, scalable to lab, production, or field deployment needs.
Frequency coverage and extensibility: Supports both Sub-6 GHz (FR1) and mmWave (FR2) testing, with customizable options for absorbers, connectors, and feed systems, future-ready for evolving wireless standards.

Services, Design, and Integration

Comprehensive RF shielding: Prevents outside electromagnetic interference from entering the test volume and minimizes internal leakage, ensuring accurate and repeatable OTA measurements.

Integrated positioning and automation: Works with Orbis antenna positioners and DUT controllers (standard REST API support) to automate antenna, beamforming, MIMO, and throughput testing. .
Modular form factors: Available as tunnel-style shielded rooms, container-based OTA chambers, or compact shielded boxes, scalable to lab, production, or field deployment needs.
Frequency coverage and extensibility: Supports both Sub-6 GHz (FR1) and mmWave (FR2) testing, with customizable options for absorbers, connectors, and feed systems — future-ready for evolving wireless standards.

Common Applications

5G OTA chamber measurements: measuring beamforming performance, radiation patterns, EIRP, and TIS.
Production and R&D testing: for smartphones, IoT modules, automotive sensors, and telecom equipment.
Field-deployable test labs: containerized tunnel chambers for on-site verification and testing.

Are you ready to set up your RF test environment?

With Orbis’ RF shielded chamber solutions, you can perform OTA testing across both current and future wireless standards. Orbis can support your needs, whether it’s a compact test enclosure, a tunnel chamber for production, or a custom 5G OTA chamber.
